Datasheet: 4030B (Texas Instruments)

Cmos Quad Exclusive-or Gate



Скачать: PDF   ZIP
Texas Instruments
Data sheet acquired from Harris Semiconductor
SCHS035C Revised September 2003
The CD4030B types are supplied in 14-lead
hermetic dual-in-line ceramic packages (F3A
suffix), 14-lead dual-in-line plastic packages (E
suffix), 14-lead small-outline packages (M, MT,
M96, and NSR suffixes), and 14-lead thin shrink
small-outline packages (PW and PWR suffixes).
