Datasheet: F13 (Raltron Electronics Corp.)

SURFACE MOUNT MONOLITHIC CRYSTAL FILTER



Скачать: PDF   ZIP
Raltron Electronics Corp.
Raltron Electronics Corporation 10651 NW 19th St. Miami, Florida 33172 U.S.A.
Tel: 305-593-6033 Fax: 305-594-3973 e-mail: sales@raltron.com Internet: http://www.raltron.com
SURFACE MOUNT MONOLITHIC CRYSTAL FILTER
FREQUENCY RANGE
20.00 MHz TO 45.00 MHz
PASS BANDWIDTH AT 3dB
3.75 KHz MIN
ATTENUATION BANDWIDTH AT 10dB
12.5 KHz MAX
RIPPLE
1.0 dB MAX
INSERTION LOSS
4.0 dB MAX
ATTENUATION GUARANTEED
AT Fo - 910 KHz 40 dB MIN
TERMINAL IMPEDANCE
SPECIFIC TO PRODUCT MODEL
OPERATING TEMPERATURE RANGE
-20C TO +70C
1.5 DIA
.06 DIA
.079
2.0
1.75
.069
1.7
16.0
.630
5.4
.213
7.9
.311
.315
7.5
.295
.067
8.0
M A R K I N G
A R E A
.276 .008
7.0 0.2
.197 .008
5.0 0.2
1
3
4
6
6 X .039
6 X 1.0
.177
4.6
2.54
10 - (R 0.3)
.100
.051 .008
1.3 0.2
2
5
2 X 12-(R 0.15)
2 X 12-(R .006)
2 - (R 0.3)
2 - (R .008)
6 - 1.2
6 - .047
6.68
.263
2.0
.078
4.0
.157
1.4
.055
FEATURES
1.2 mm MAXIMUM HEIGHT
EXCELLENT STABILITY OVER TEMPERATURE
TAPE AND REEL PACKAGING
SERIES F13
SPECIFICATIONS
OUTLINE DRAWING
SOLDER PATTERN
F13
PIN
FUNCTION
1
GND
2
GND
3
IN/OUT
4
GND
5
GND
6
OUT/IN
PIN CONNECTION
CARRIER TAPE DIMENSIONS
SOLDER REFLOW PROFILE
PREHEATING
REFLOW
COOLING
240 C
150 C
25 C
60
TIME (SECONDS)
TEMPERATURE
200
1 TO 9 C/s
1 TO 5 C/s
10 s
1 TO 5 C/s
PACKAGING
180 mm REEL DIAMETER,16 mm TAPE WIDTH, 8 mm PITCH
QUANTITY: 1000 PIECES PER REEL
PART NUMBERING SYSTEM
SERIES
-
FREQUENCY
MODE
PASS BANDWIDTH
POLES
F13
IN MHz
F: FUNDAMENTAL
M: THIRD OVERTONE
10 KHz = 20
A = 2 POLES
EXAMPLE: F13-45M20A
DEPENDENT UPON FREQUENCY
