Datasheet: 499-90-216-10-009 (Precid-Dip Durtal)

PCB connectors 2.54 mm Single row / double row Solder tail



Скачать: PDF   ZIP
Precid-Dip Durtal
45
Series 399 / 499
PCB connectors 2.54 mm
Single row / double row
Solder tail
Right angle pin connectors, solder tail
Pin connectors with pins
0.47 mm
For corresponding connectors see pages
36 to 42 and 47, 48
New:
Pin connectors with selective plated precision screw machined
pin, plating code Z1.
Connecting side 1: gold plated
soldering/PCB side 2: tin plated
Ordering information
Replace xx with the number of poles, e.g. 499-93-2xx-10-009
for a double row version with 8 pins per row becomes:
499-93-216-10-009
399-10-1xx-10-009
399-90-1xx-10-009
399-Z1-1xx-10-009
Right angle pin connector: single
row
Availability from: 1 to 64 contacts
Standard number of contacts 5,
6, 8, 10, 14, 16, 20, 21, 25, 30,
32, 48, 56, 60, 64
499-10-2xx-10-009
499-90-2xx-10-009
499-Z1-2xx-10-009
Right angle pin connector:
double row
Availability from: 4 to 72 contacts
Standard number of contacts 40,
44, 56, 64, 72
Platings
Sleeve
Clip
Pin
10
0,25
m Au
90
5
m Sn Pb
Z1
1: 0.25
m Au
2: 5
m Sn Pb
