Datasheet: F340 (Fox Electronics)

• 3.2 x 2.5 x 1.1mm• 2.5V Operation• HCMOS• Low Current StandbyFunction (10µA MAX)



Скачать: PDF   ZIP

45
2004 FOX ELECTRONICS
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1(239)693-0099 FAX +1(239)693-1554
http://www.foxonline.com
2.5V HCMOS SMD OSCILLATOR WITH STANDBY
MODEL: F340 SERIES
FEATURES
2.5V Operation
HCMOS Output
Low Power Consumption
Standby Function
Tape and Reel
(2,000 pcs. STD)
1
Inclusive of 25C tolerance, operating temperature range, input voltage change, load change,
aging, shock, and vibration. *Excludes Shock/Vibration
2
An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
Note: A 0.01F bypass capacitor should be placed between VDD (Pin 4) and GND (Pin 2) to
minimize power supply line noise.
All specifications subject to change without notice. Rev. 6/1/04
1.800 ~ 50.000 MHz
-55C ~ +125C
2.5V 5%
20mA
45% ~ 55%
6nS
6nS
10% V
DD
90% V
DD
Min
2mA Min
-2mA Min
15pF
10A
5mS
150nS
5mS
PARAMETERS
Frequency Range (F
O
)
Storage Temperature Range (T
STG
)
Supply Voltage
(V
DD
)
Input Current
(I
DD
)
Output Symmetry (50% V
DD
)
Rise Time (10% ~ 90% V
DD
) (T
R
)
Fall Time (90% ~ 10% V
DD
) (T
F
)
Output Voltage
(V
OL
)
(V
OH
)
Output Current
(I
OL
)
(I
OH
)
Output Load
(HCMOS)
Standby Current
Start-up Time
(T
S
)
Output Disable Time
2
Output Enable Time
2
ELECTRICAL CHARACTERISTICS
MAX
(unless otherwise noted)
All dimensions are in millimeters.
OUTPUT (Pin 3)
ACTIVE
ACTIVE
High Z
ENABLE / DISABLE FUNCTION
INH (Pin 1)
OPEN
2
'1' Level V
IH
70% V
DD
'0' Level V
IL
30% V
DD
Frequency
Stability
1
100PPM
100PPM
50PPM
50PPM
25PPM
25PPM*
20PPM*
Operating
Temperature (C)
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
Frequency
Range (MHz)
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
F340
F340R
F345
F345R
F346
F346R
F348
Model
Number
PRELIMINARY
Learn more about:
Part Marking Identification
Mechanical Specification
Internet required
Part Number
639-Frequency-xxxxx
643-Frequency-xxxxx
640-Frequency-xxxxx
644-Frequency-xxxxx
641-Frequency-xxxxx
645-Frequency-xxxxx
642-Frequency-xxxxx
PART NUMBER SELECTION
